includes compartment shelves and mounting hardware, but does not include items
mounted in the compartments. Non-metallic materials may be black or gray.
2.1.9.3 Horizontal Reflective striping. Horizontal reflective striping in accordance with 15.9.3 of
NFPA 1901 shall be applied around the vehicle in an approximate plane with the headlights.
Bright metal trim or anodized parts may interrupt the reflective stripes. The pattern shall be 10
inches wide with three reflective stripes (one inch reflective, one inch body color, six inches
reflective, one inch body color, and one inch reflective). The reflective stripes shall be white for
vehicles painted Candy Apple Red and Desert Sand.
2.1.9.4 Chevron Striping. In accordance with 15.9.3.2 of NFPA 1901 at least 50 percent
of the rear-facing vertical surfaces, visible from the rear of the apparatus, excluding any pump
panel areas not covered by a door, shall be equipped with retroreflective striping in a chevron
pattern sloping downward and away from the centerline of the vehicle at an angle of 45 degrees.
3M part number 983-17 (red) and 983 -23 (florescent yellow/green) reflective diamond grade or
equivalent shall be utilized. Each stripe in the chevron shall be a single color alternating between
red and fluorescent yellow in accordance with 15.9.3.2.1. Each stripe shall be 6-inches (150 mm)
in width in accordance with 15.9.3.2.2 of NFPA 1901 and the example provided below.
