MIL-DTL-52031E
3.14 Identification marking. The fire extinguisher shall be identified in accordance with MIL-STD-130.
3.14.1 Extinguisher cylinder. Each extinguisher cylinder shall be plainly and permanently marked in
accordance with DOT regulations by stamping on the shoulder of the cylinder, starting near the neck and
in sequence downward as follows:
One side
DOT specification and service pressure, and "SPUN" when spun cylinders are
supplied, in characters not less than 3/16 inches high. The symbol of the
Department of the Army, "DA," and the manufacturer s serial number-letters in
characters not less than 1/4 inch high.
The manufacturer s mark or symbol.
Third party inspection mark or Government inspector s stamp, when applicable.
Other side
(Opposite the above marking, and as near the neck as possible).
Military specification number.
Original pressure test date (month and year).
3.15 Treatment and painting.
3.15.1 Treatment and painting of fire extinguisher bracket. The Hand Held fire extinguisher bracket shall
be painted Finish Color No. 17178 or FED-STD-595.
3.15.2 Fire extinguisher and components. The portion of the extinguisher and its components and parts
normally painted shall be treated and painted in accordance with Table below, Finish Color No. 12.205;
Pretreatment
Primer
Topcoat
All environments other
Master Painters
than marine
Institute (MPI),
TT-P-644
Reference #94, exterior
DoD-P-15328
Or SSPC-Paint25
alkyd, semi-gloss, MPI
Gloss Level 5
For Marine
DoD-P-15328
TT-P-645
MIL-PRF-24635
Environments
Coats (Marine
Environments)
-
1 (1)
1 (2)
Dry Film Thickness
0.3-0.5
1.0-1.5
1.0-1.5
(mils) per Applied Coat
(0.3-0.5)
(min 2.0)
(min 2.0)
(Marine Environments)
3.16 Workmanship. All parts, components, and assemblies of the fire extinguisher shall be clean and free
from sand, dirt, fins, pits, spurs, scale, flux, and other harmful extraneous material. All external edges
shall be rounded, beveled or de-burred. Internal parts and surfaces requiring sharp edges will be formed
only as necessary. All burrs and rough edges shall be removed.
4. VERIFICATION
4.1 Classification of Inspections.
The inspection requirements specified herein are classified as follows:
7
